ABC cable--Covered Line Wire with Aluminum Conductor

  • Standard: ASTM
  • Insulation: XLPE PE PVC
  • Conductor: AAC, AAAC, ACSR
  • Jacket: XLPE
  • Cross section: 10mm2-300mm2
  • Conductor Type: Stranded

We're here to help:

Easy ways to get the answers you need.

(※ Click this button to inquiry)
share with :
  • Covered Line Wire ABC
  • ABC cable with Aluminum Conductor
  • Aerial Bundled Cable
  • overhead  abc power cable
  • Aerial Bunched Cable
■ Specifications

 ApplicationCovered line Wire is used primarily for 600v overhead secondary distribution lines. It is not an electrically insulated conductor and is treated as bare conductor when installed.

 ConstructionThe conductors are 1350-H19 Aluminum Wire ,6201-T81 Aluminum Alloy or ACSR conductors, concentrically stranded and covered for weather proofing with polyethylene, high density polyethylene(HDPE) or cross-linked polyethylene(XLPE).


 StandardASTM B-230 - Aluminum Wire 1350-H19 for Electrical Purposes
ASTM B-231 - Concentric-Lay-Stranded Aluminum Conductors
ASTM B-232 - Concentric-Lay-Stranded Aluminum Conductors, Coated-Steel Reinforced (ACSR)
ASTM B-399- Concentric-Lay-Stranded 6201-T81 Aluminum Alloy Conductors
ICEA S-61-402-: Thermoplastic-insulated Wire And Cable For The Transmission And Distribution Of Electrical Energy
ICEA S-66-524-XLPE Insulated Wire and Cable For the Transmission and Distribution of Electrical Energy




■ Technical Data

 Parameter

Covered line Wire--Aluminum Conductor

Code Name

Size
AWG or kcmil

No.of wires

Insulation Thickness
(mm)

Overall
Diameter
(mm)

Rated Strength
(kg)

Nominal Weight
(kg/km)

Allowable Ampacity+
A

Al

LDPE

HDPE

XLPE

AAC

Plum

6

7

0.762

6.198

255

36.61

50.66

51.27

51.27

100

Apricot

4

7

0.762

7.239

400

58.19

75.57

76.33

76.33

135

Peach

2

7

1.143

9.703

612

92.56

126.09

127.55

127.55

180

Nectarine

1

7

1.143

11.481

789

116.67

167.31

169.52

169.52

210

Quince

1/0

7

1.524

12.395

903

147.48

203.7

206.14

206.14

240

Haw

1/0

19

1.524

12.522

980

147.48

204.49

206.96

206.96

240

Orange

2/0

7

1.524

14.834

1139

186.02

257.9

261.02

261.02

280

Ironwood

2/0

19

1.524

13.691

1211

186.02

250.41

253.21

253.21

280

Fig

3/0

7

1.524

16.307

1377

233.64

315.53

319.08

319.08

320

Lemon

3/0

19

1.524

14.986

1501

233.64

306.53

309.7

309.7

320

Olive

4/0

7

1.524

16.307

1728

296.14

378.04

381.58

381.58

370

Pomegranate

4/0

19

1.524

16.459

1823

296.14

379.09

382.69

382.69

370

Sassalras

250

19

1.524

17.628

2043

348.68

439.88

443.84

443.84

420

Mulberry

266.8

19

1.524

17.653

2182

372.19

463.59

467.55

467.55

460

Basswood

300

19

1.524

18.999

2404

419.66

520.91

525.3

525.3

478

Anona

336.4

19

1.524

19.964

2697

469.51

578.04

582.75

582.75

495

Chinquapin

350

19

1.524

20.269

2790

488.12

598.98

603.79

603.79

525

Molles

397.5

19

2.032

22.454

3123

555.08

707.29

713.88

713.88

550

Sumac

450

37

2.032

23.673

3719

628

791.79

798.89

798.89

600

Huckleberry

477

37

2.032

24.257

3810

665.21

834.63

841.98

841.98

610

ACSR

Walnut

6

6/1

0.762

6.553

540

36.46

69.94

71.43

71.43

105

Butternut

4

6/1

0.762

7.874

844

58.04

107.15

107.15

108.64

135

Hickory

4

7/1

0.762

8.052

1070

58.04

120.54

122.03

123.52

135

Pignut

2

6/1

1.143

10.312

1293

92.27

175.6

177.09

178.58

180

Beech

2

7/1

1.143

10.643

1651

92.27

199.41

199.41

202.39

180

Chestnut

1

6/1

1.143

11.303

1610

116.37

217.27

218.76

220.25

210

Almond

1/0

6/1

1.524

13.157

1987

146.73

282.75

284.24

287.21

235

Pecan

2/0

6/1

1.524

14.402

2404

184.98

348.23

349.72

349.72

290

Filbert

3/0

6/1

1.524

15.799

3003

233.34

430.08

433.05

437.52

305

Buckeye

4/0

6/1

1.524

17.348

3787

294.21

531.27

535.74

540.2

345

Hackberry

266.8

18/1

1.524

18.517

3121

372.63

525.32

528.3

534.25

356

AAAC

Maple

6

7

0.762

6.553

503

42.41

59.53

61.01

61.01

78

Hornbeam

4

7

0.762

7.874

798

67.56

89.29

90.78

92.12

145

Linden

2

7

1.143

10.312

1270

107.44

147.33

147.33

148.82

190

Oilnut

1/0

7

1.524

11.887

2023

170.99

238.11

247.03

247.03

250

Waterash

2/0

7

1.524

14.402

2445

215.63

291.68

302.01

302.01

290

Shellbark

3/0

7

1.524

15.799

3080

271.59

358.65

370.55

370.55

335

Planetree

4/0

7

1.524

17.348

3883

342.57

443.47

456.86

456.86

385
