Cross-linking Polyethylene Insulated Power Cables with Rated Voltages from 6kV up to 35kV

  • Type: Unarmoured cables
  • Sheath thickness: 1.4mm
  • Calculated diameter: 17.4mm
  • Sheath thickness: 2.0mm
  • Calculated diameter: 33.4mm

We're here to help:

Easy ways to get the answers you need.

(※ Click this button to inquiry)
share with :
  • xlpe cable 185mm
  • 33kv cable xlpe price
  • insulated power cables
  • rated voltages from 6kV up to 35kV
  • cable rated voltages 6kV
■ Specifications

►Products application
XLPE polyethylene insulated power cables, This product is applicable to being fixedly laid on the transmission and distribution line of alternative current rating 50Hz and rated voltage up to 6/35 kV with the use for power transmission, which is applied to the range of distribution network, industrial equipments, high electricity consumption places etc.
XLPE polyethylene insulated flame-retardant power cables, The product has good performance on preventing fire burning on the circuit, which can avoid fire accidents and losses. The products can be used in subway, tunnels and high-rise buildings etc.
XLPE polyethylene insulated low-smoke zero-halogen flame-retardant power cables, The environmental product has good performance on flame-retardant, corrosion resistance and low-smoke, which is suitable to be laid in crowded places, such as subway, shopping mall or schools etc.
This product is the normal used cable, not suitable for some special places, such asunder water, ship, nuclear station, etc.

►Technique features
XLPE polyethylene insulated power cables, this product is manufactured by parasitical cross-linking procedure, the straight-chain polyethylene will be changed as network structure by use this method, which transformed thermoplastic material into thermosetting material. The working temperature is up to 90℃, which can raise the cable current capacity highly.
XLPE polyethylene insulated power cables, the product has good performance on electrical characteristic, heat resistance, chemical resistance, environmental stress cracking resistance and aging resistance, all which make the cable has a long useful life.
XLPE polyethylene insulated low-smoke zero-halogen flame-retardant low-smoke zero-halogen flame-retardant power cables; the product is a new environmental protected cable with good flame-retardant performance, which just releases few poisonous and corrosive gases. The product has good performance on electrical characteristic, heat resistance, chemical resistance, environmental stress cracking resistance and aging resistance, all which makes the cable has a long useful life.
The product characteristic is simple structure, short production period, easy installation and maintained, especially there is no limit of head drop during the cable laying.

►Operating characteristics
1. Rated Voltage
Rated Voltage of cable U0/U(Um),as follow:
U0/U(Um)=3.6/6(7.2)-6/6(7.2)-6/10(12)-8.7/10(12)-8.7/15(17.5)-12/20(24)-18/30(36)-21/35(40.5)-26/35(40.5)kV。
2. The rated temperature of conductor
The maximum assigned temperature of the cable conductor is 90℃.
During having a short circuit, lasting less than 5 seconds, the maximum temperature of the cable conductor shall not be above 250℃.
3. Ambient temperature for laying
The ambient temperature for laying shall be above 0℃, otherwise the cable need be preheated.
4. The bend radius
The minimum bend radius of the cable see the table 2

Table2 The minimum bend radius of the cable

Item Single -core Three -core
Unarmored Armored Unarmored Armored
Minimum bend radius of the cable in course of installation. 20D 15D 15D 12D
The minimum bend radius of the cable close to the junction box and terminal 15D 12D 12D 10D
Note: D is outer diameter of the cable


►1. Laying
There is no limit of head drop during the cable laying.
The cable may be laid in indoor, outdoor, air and soil. The cable may be immersed in water locally.
The cable may be laid in tunnel, pipe, trench, conduit and on cable bridge. The armored cable can be laid underground, and the wire- armored cable can be laid vertically.
The single core cable mustn't be laid in the magnetic metal pipes.
The environment of cable laying shall be in good heat dissipation condition.

►2. The requirements on transportation and storage
The cable reels shall not be delivered and stored in flat state.
It is strictly forbidden to push the cable reel from the high level in order to prevent the cable from damages
If the cable should be used sectionally, the head of the cable must be sealed in order to prevent water intake.


■ Technical Data

3.6/6kV XLPE Insulated unarmoured cables

Nominal
cross area of conductor
(mm2)
Insulated thickness (mm) Single-core Three-cores
Sheath thickness (mm) Calculated diameter (mm) Weight of cable(kg/km) Sheath thickness
 (mm)
Calculated diameter
 (mm)
Weight of cable (kg/km)
YJV YJY YJLV YJLY YJV YJY YJLV YJLY
10 2.5 1.4 17.4 342 313 280 250 2.0 33.4 1341 1256 1154 1068
16 2.5 1.5 18.6 425 392 325 293 2.0 36.0 1632 1536 1332 1236
25 2.5 1.5 21.6 524 488 373 337 2.1 40.1 1841 1734 1385 1279
35 2.5 1.5 22.6 635 597 426 387 2.2 42.4 2180 2063 1549 1432
50 2.5 1.6 24.0 779 736 494 451 2.3 45.4 2670 2537 1814 1681
70 2.5 1.6 25.7 1005 957 594 546 2.4 49.1 3398 3247 2160 2009
95 2.5 1.7 27.4 1280 1226 710 655 2.5 52.8 4274 4102 2556 2384
120 2.5 1.7 28.9 1536 1477 816 757 2.6 56.0 5093 4902 2925 2734
150 2.5 1.8 30.6 1846 1781 943 877 2.8 59.7 6077 5864 3356 3143
185 2.5 1.8 32.3 2215 2143 1088 1016 2.9 63.3 7258 7022 3865 3628
240 2.5 1.9 34.7 2770 2689 1303 1222 3.0 68.4 9053 8781 4639 4367
300 2.5 2.0 37.0 3380 3290 1536 1446 3.2 73.5 10992 10683 5441 5132
400 2.5 2.1 40.2 4294 4189 1880 1775 3.4 80.2 13855 13492 6589 6226
500 2.5 2.2 42.3 5724 5698 2722 2701 3.7 86.2 17131 17012 8045 7960
630 2.5 2.3 45.9 7010 6982 3190 3169
800 2.5 2.4 49.8 8420 8396 3560 3542


3.6/6kV XLPE Insulated three-core steel tape armoured cables

Nominal cross
area of conductor/mm2
Insulated thickness (mm) Inner sheath thickness (mm) Steel tape specifications Sheath thickness (mm) Calculated diameter (mm) Weight of cable (kg/km)
YJV22 YJY22 YJLV22 YJLY22 YJV23 YJY23 YJLV23 YJLY23
3*10 2.5 1.2 0.5*30 2.1 38.0 2100 2033 1912 1846 1996 1930 1809 1743
3*16 2.5 1.2 0.5*30 2.1 40.5 2457 2382 2157 2083 2342 2268 2043 1968
3*25 2.5 1.2 0.5*30 2.2 44.7 2725 2643 2270 2188 2599 2517 2144 2061
3*35 2.5 1.3 0.5*35 2.3 47.1 3131 3040 2500 2408 2992 2901 2361 2269
3*50 2.5 1.3 0.5*35 2.4 50.3 3706 3603 2851 2747 3551 3447 2695 2591
3*70 2.5 1.4 0.5*35 2.5 54.0 4540 4422 3303 3184 4364 4246 3126 3008
3*95 2.5 1.5 0.5*35 2.6 57.9 5527 5392 3809 3675 5327 5192 3609 3475
3*120 2.5 1.5 0.5*35 2.7 61.2 6446 6296 4277 4127 6224 6075 4056 3906
3*150 2.5 1.6 0.5*45 2.9 65.0 7542 7375 4821 4654 7296 7130 4575 4408
3*185 2.5 1.6 0.5*45 3.0 68.8 8840 8654 5446 5261 8568 8383 5175 4989
3*240 2.5 1.7 0.5*45 3.1 74.1 10821 10608 6407 6193 10491 10278 6077 5864
3*300 2.5 1.8 0.5*45 3.3 79.3 13651 13412 8100 7861 13272 13033 7721 7482
3*400 2.5 2.0 0.8*60 3.6 87.6 16846 16561 9580 9294 16423 16138 9157 8871
3*500 2.5 2.3 0.8*60 4.0 94.3 20087 19967 11256 11136 19957 19892 11126 11036
